Install Hadoop 2.2.0 on Ubuntu Linux 13.04 (Single-Node Cluster)

This tutorial explains how to install Hadoop 2.2.0/2.3.0/2.4.0/2.4.1 on Ubuntu 13.04/13.10/14.04 (Single-Node Cluster). This setup does not require an additional user for Hadoop. All files related to Hadoop will be stored inside the `~/hadoop` directory.

• Install a JRE. If you want the Oracle JRE, follow this post.

• Install SSH:

  sudo apt-get install openssh-server


  Generate a SSH key:

  ssh-keygen -t rsa -P ""


  Enable this SSH key:

  cat $HOME/.ssh/id_rsa.pub >> $HOME/.ssh/authorized_keys


  (Optional) Disable SSH login from remote addresses by setting in /etc/ssh/sshd_config:

  ListenAddress 127.0.0.1


  Test local connection:

  ssh localhost


  If ok, then exit:

  exit


  Otherwise debug :)

• Download Hadoop 2.2.0 (or newer releases)

• Unpack, rename and move to the home directory:

  tar xvf hadoop-2.2.0.tar.gz
  mv hadoop-2.2.0 ~/hadoop


• Create HDFS directory:

  mkdir -p ~/hadoop/data/namenode
  mkdir -p ~/hadoop/data/datanode


• In file ~/hadoop/etc/hadoop/hadoop-env.sh add (after the comment The java implementation to use.):

  export JAVA_HOME="`dirname $(readlink /etc/alternatives/java)`/../"
  export HADOOP_COMMON_LIB_NATIVE_DIR="~/hadoop/lib"
  export HADOOP_OPTS="$HADOOP_OPTS -Djava.library.path=~/hadoop/lib"


• In file ~/hadoop/etc/hadoop/core-site.xml (inside <configuration> tag):

  <property>
    <name>fs.default.name</name>
    <value>hdfs://localhost:9000</value>
  </property>


• In file ~/hadoop/etc/hadoop/hdfs-site.xml (inside <configuration> tag):

  <property>
    <name>dfs.replication</name>
    <value>1</value>
  </property>

  <property>
    <name>dfs.namenode.name.dir</name>
    <value>${user.home}/hadoop/data/namenode</value>
  </property>

  <property>
    <name>dfs.datanode.data.dir</name>
    <value>${user.home}/hadoop/data/datanode</value>
  </property>


• In file ~/hadoop/etc/hadoop/yarn-site.xml (inside <configuration> tag):

  <property>
    <name>yarn.nodemanager.aux-services</name>
    <value>mapreduce_shuffle</value>
  </property>

  <property>
    <name>yarn.nodemanager.aux-services.mapreduce.shuffle.class</name>
    <value>org.apache.hadoop.mapred.ShuffleHandler</value>
  </property>


• Create file ~/hadoop/etc/hadoop/mapred-site.xml:

  cp ~/hadoop/etc/hadoop/mapred-site.xml.template ~/hadoop/etc/hadoop/mapred-site.xml


  And add (inside <configuration> tag):

  <property>
    <name>mapreduce.framework.name</name>
    <value>yarn</value>
  </property>


• Add Hadoop binaries to PATH:

  echo "export PATH=$PATH:~/hadoop/bin:~/hadoop/sbin" >> ~/.bashrc
  source ~/.bashrc


• Format HDFS:

  hdfs namenode -format


• Start Hadoop:

  start-dfs.sh && start-yarn.sh


  If you get the warning:

  WARN util.NativeCodeLoader: Unable to load native-hadoop library for your platform... using builtin-java classes where applicable


  It is because you are running on 64bit but Hadoop native library is 32bit. This is not a big issue. If you want (optional) to fix it, check this.

• Check status:

  jps


  Expected output (PIDs may change!):

  10969 DataNode
  11745 NodeManager
  11292 SecondaryNameNode
  10708 NameNode
  11483 ResourceManager
  13096 Jps


  N.B. The old JobTracker has been replaced by the ResourceManager.

• Access web interfaces:

  • Cluster status: http://localhost:8088
  • HDFS status: http://localhost:50070
  • Secondary NameNode status: http://localhost:50090



• Test Hadoop:

  hadoop jar ~/hadoop/share/hadoop/mapreduce/hadoop-mapreduce-client-jobclient-2.2.0-tests.jar TestDFSIO -write -nrFiles 20 -fileSize 10


  Check the results and remove files:

  hadoop jar ~/hadoop/share/hadoop/mapreduce/hadoop-mapreduce-client-jobclient-2.2.0-tests.jar TestDFSIO -clean


  And:

  hadoop jar ~/hadoop/share/hadoop/mapreduce/hadoop-mapreduce-examples-2.2.0.jar pi 2 5


• Stop hadoop:

  stop-dfs.sh && stop-yarn.sh


Posted on November 23, 2013
